Features

• G.M.P bare shaft self priming pumps are a popular choice to long couple to a wide variety of power drive options including petrol or diesel engine, electric motor, hydraulic motor or can be PTO driven.
• Cast Iron Construction
• Open vein style Impeller ideally suited for pumping permissible compressible solids
• Fast self priming up to 6 M vertical lift
• Carbon ceramic seal for B3XR-A HYD and G-3TMK-A and upgraded dirty
  water specialist silicon carbide mechanical seal with alumina counterface
  for B3XR-A/ST HYD22 andB4XR-A/ST HYD
• Inbuilt cast iron foot mounting and compact design
• Operator friendly trash inspection door providing easy pump cleanout
  without pipework disconnection on B3XR-A/ST & B4XR-A/ST/W

Applications

• Cast Iron Industrial Applications:
  • Industrial waste pump out
  • Livestock effluent pump out
  • Public sewage works
  • Abattoir waste pump out
  • Piggeries, chicken processing, feed lots
  • Wash bay water recirculation
  • Batch plant recirculation
  • Mineral processing
  • Quarry dewatering

Specifications

• Cat Part #: AS91
• Inlet: 3″
• Outlet: 3″
• Required kW: 7.5 kW
• Speed: 2,900 RPM
• Pressure: 43 PSI
• Max Head: 31 m
• Capacity: 1,500 L/min
• Solid Size: 24 mm
• Weight: 46.5 kg
• Dimensions: L 290 x W 453 x H 400 mm
