Features
- Triplex plunger pump in line
- Symmetric crankcase featuring top and bottom fixing for easy right to left shaft conversion
- Shaft support tapered roller bearings oversized for long duration
- PATENTED stainless steel suction/delivery valves featuring spherical design of sealing areas
- Seals: new high reliability hight pressure seal with low-pressure lubrication and recirculation chamber
- Pump body: aluminium alloy
- Head: brass
- Camshaft: forged steel
- Splash lubrication
- Connecting rods: special antifriction alloy
- Guiding piston: stainless steel
- Solid ceramic plungers
- Steel valve cage
- Double sight glass oil
Specifications
- Pressure: 7,252 PSI
- Flow: 30 L/min
- Speed: 1,450 RPM
- Power: 29.3KW, 39.8HP
