Features
- ITC air-cooled diesel engines are engineered with quality parts to improve durability, boost engine performance and lengthen service intervals. Coupled with a cast iron cylinder liner, you’ve got a machine that won’t quit.
- For generators
- Reliable power output
- Rugged Design for most conditions and environments
- Integrated sound dampener (silencer/muffler) reduces noise levels
- Direct Injection means better performance
- Low fuel and oil consumption
Specifications
- Type: Single cylinder, vertical, 4-stroke, air-cooled
- Bore x Stroke: 92 × 75 mm
- Displacement: 0.498 L (498 cc)
- Compression Ratio: 20:1
- Rated Speed: 3,000 RPM
- Rated Power: 7.35 kW (10 HP) / 8.0 kW (11 HP)
- Max. Power: 8.0 KW (11 HP) / 8.8 kW (12 HP)
- Fuel Tank Capacity: 5.5 L
- Fuel Consumption: ≤272 g / 280 kw per hr
- Lube Oil Capacity: 1.75 L
- Starting: Electric
- Output Shaft: Crankshaft / Camshaft
- Fuel trademark: 0#(summer), -10#(winter) diesel
- Oil trademark: CD grade or SAE10W-30 15W-40
- Weight: 57 kg
- Dimensions: 417 × 470 × 500 mm
- Shipping: 515 × 480 × 580 mm
- Loading Capacity: 192/400
